Introduction to the C-1500N

Description

The CHEM-FEED® C-1500N Diaphragm Pump is a positive displacement chemical metering pump that delivers reliable chemical feed for a wide variety of chemicals and solutions.  The C-1500N has a fixed-speed AC motor as a single diaphragm pump with non-loss mechanical cam and stroke adjustment for varying flow output.

Product Overview / Features

• The C-1500N pump can deliver up to 9.5 GPH (36 LPH) at O psi. (See flow curve for outputs at certain pressures.)
• AC Motor types available.
• All ball bearings and permanently lubricated gear motor for smooth, quiet, powerful operation.
• Double ball inlet and outlet cartridge-type ceramic check valves.
• Stroke adjustment from 5-100% via high-strength mechanical cam.
• Wetted parts are PVDF pump head and adapters, Aflas and FKM o-rings, Ceramic balls (or Teflon), and PTFE-coated EP diaphragm.
• 1 Year Limited Warranty.

Applications

The C-1500N is designed to provide smooth chemical feed for various chemicals and processes.  It can reliably pump chemicals that require a fixed speed, reliable, consistent flow with minimal maintenance.

The C-1500N pump is ideal for pumping small injections at a high rate for use in OEM equipment, custom machinery, dosing systems, and other types of wet processing equipment like commercial cooling towers, boilers, car wash systems, cleaning systems, pH controllers, laundry, and food/beverage processing.
